| RD-33# Light/Medium Duty Racking System | |||
|---|---|---|---|
| Standard Load Capacity | 300KG / Layer | ||
| Layers | Standard is 4 layers (can be custom made) | ||
| Colour Options | Gray white / Sand blue / Customizable | ||
| Standard Specifications | Length: 2000 mm | Width: 600 mm | Height: 2000 mm | ||
| Key Features | Removable shelves reduce the packaging volume while maintaining the same load-bearing capacity, saving a lot of transportation costs and improving product competitiveness. | ||
| 40HQ Container Capacity | A 40HQ high container can accommodate 425 sets of 200kg shelves. With a carefully designed structure, it is possible to reduce the packaging volume by 40% while maintaining the same load-bearing capacity. | ||
| Load Limit (KG) | Laminate Thickness | Column Specification | Crossbeam Specification |
| 100 KG | 0.30 mm | 50*25*0.5 mm | 50*30*0.5 mm |
| 200 KG | 0.35 mm | 70*35*0.7 mm | 60*35*0.6 mm |
| 300 KG | 0.50 mm | 60*30*1.0 mm | 70*33*1.0 mm |
| 600 KG | 0.50 mm | 70*33*1.4 mm | 70*35*1.2 mm |
